Thermaltake Core P6 Tempered Glass Mid Tower Chassis, Snow White
Thermaltake Core P6 Tempered Glass Mid Tower Chassis, Snow White
Couldn't load pickup availability
Thermaltake Core P6 TG Snow Mid Tower Chassis: The Epitome of Flexibility
The Core P6 TG Snow Mid Tower Case stands as a testament to Thermaltake's commitment to offering maximum flexibility and innovative design. This versatile chassis, a smaller version of the Core P8 TG Full Tower Case, offers a unique blend of closed and open styles, all while being the latest addition to the renowned open-frame Core Series.
TT Premium - Quality Beyond Measure
Thermaltake's TT Premium isn't just about quality; it's a symbol of passion for DIY, modding, and innovation in the PC hardware market. The TT Premium values include Excellent Quality, Unique Design, Diverse Combinations, and Boundless Creativity to cater to every enthusiast's high-performance PC needs.
Transformable Chassis
The Core P6 TG Snow is a dual-form ATX mid tower case, which effortlessly transforms into an open-frame design upon removal of the front and top tempered glass panels.
Two-Way Placement Layout
Designed for two different placements - wall-mounted or vertical - the Core P6 TG Snow is a customizable chassis that caters to your viewing preferences while delivering outstanding cooling performance.
4mm Thick Tempered Glass Panels
With three 4mm thick tempered glass panels, the Core P6 TG Snow sets the industry standard. These enlarged glass windows allow you to proudly showcase your RGB components in all their brilliance.
Flexible GPU Display Options
The rotational PCI-E slots provide the flexibility to display your graphics card either horizontally or vertically, offering more options for configuring your system.
PSU Cover & Riser GPU Support Bracket
The built-in PSU cover conceals cables while ensuring optimal ventilation. An additional L-shape GPU bracket in the accessory box supports both vertical and horizontal GPU placement, reducing strain on the PCI-E slots, especially with high-end graphics cards. Users can choose from three installation configurations.
Dust Reduction
Three super-fine magnetic filters on the right, top, and bottom offer excellent protection against external dirt and dust, and they're easily removable for cleaning.
Expansion and Liquid Cooling Solution
The Core P6 TG Snow offers ample expandability to build a comprehensive thermal solution. It supports up to a CEB motherboard, a CPU cooler with a max height of 180mm, and two-way VGA configurations up to 458mm in length. The chassis accommodates 360mm or 280mm radiators at the front, top, and right side of the motherboard, allowing for advanced air and liquid cooling options.
Handy I/O Ports
Front-right panel I/O ports include two USB 3.0, two USB 2.0, and one USB 3.2 (Gen 2) Type-C for quick and convenient access.
DMD - Dismantlable Modular Design
The Core P6 TG Snow's modular panels, racks, brackets, and pre-designed mounting arrays empower users to build their systems from the ground up with ease and simplicity.
Built for Makers
Designed to embrace the "maker movement" and 3D printing, this open-frame panoramic viewing chassis encourages creativity and modding, allowing you to bring your ideas to life with available liquid cooling components and manuals.
Unveil Endless Possibilities
With the Core P6 TG Snow Mid Tower Case, you'll have boundless possibilities to craft your dream machine, making the building process unique, innovative, and enjoyable.
Specifications,
| P/N | CA-1V2-00M6WN-00 |
| SERIES | Core |
| MODEL | Core P6 TG Snow |
| CASE TYPE | Mid Tower |
| DIMENSION (H X W X D) | 565 x 255 x 530mm (22.2 x 10 x 20.9 inch) |
| NET WEIGHT | 17.84 kg / 39.33 lbs. |
| SIDE PANEL | 4mm Tempered Glass x 3 |
| COLOR | White |
| MATERIAL | SPCC |
| COOLING SYSTEM | - |
|
DRIVE BAYS -ACCESSIBLE -HIDDEN |
4 x 3.5” or 8 x 2.5” |
| EXPANSION SLOTS | 7 (Rotatable Patented Design) |
| MOTHERBOARDS | 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX), 12” x 10.5”(CEB) |
| I/O PORT | USB 3.2 (Gen 2) Type-C x 1, USB 3.0 x 2, USB 2.0 x 2, HD Audio x 1 |
| PSU | Standard PS2 PSU (optional) |
| FAN SUPPORT | Front: 3 x 120mm, 2 x 120mm, 1 x 120mm 2 x 140mm, 1 x 140mm Top: 3 x 120mm, 2 x 120mm, 1 x 120mm 2 x 140mm, 1 x 140mm Rear: 1 x 120mm Right (M/B Side): 3 x 120mm, 2 x 120mm, 1 x 120mm 2 x 140mm, 1 x 140mm Bottom: 3 x 120mm, 2 x 120mm or 1 x 120mm 2 x 140mm, 1 x 140mm |
| RADIATOR SUPPORT | Front: 1 x 360mm, 1 x 240mm, 1 x 120mm 1 x 280mm, 1 x 140mm Top: 1 x 360mm, 1 x 240mm, 1 x 120mm 1 x 280mm, 1 x 140mm Rear: 1 x 120mm Right (M/B Side): 1 x 360mm, 1 x 240mm, 1 x 120mm 1 x 280mm, 1 x 140mm Bottom: 1 x 240mm, 1 x 120mm |
| CLEARANCE | CPU cooler height limitation: 180mm VGA length limitation: 300mm (With Reservoir) 400mm (Without Reservoir) 430mm (With Radiator) 458mm (Without Radiator) PSU length limitation: 200mm |
