SAPPHIRE NITRO+ AMD Radeon™ RX 9070 XT OC GPU 16GB GDDR6

The SAPPHIRE NITRO+ AMD Radeon™ RX 9070 XT OC GPU is a high-performance graphics card powered by AMD RDNA™ 4 architecture. It features 16GB of GDDR6 memory on a 256-bit memory bus, a boost clock of up to 3060 MHz, and a game clock of up to 2520 MHz.

Designed for high-end 4K gaming and demanding graphics workloads, it combines SAPPHIRE TRI-X cooling technology with AeroCurve fan blades, optimized composite heatpipes, a metal backplate, ARGB lighting, and advanced power delivery.

Key Features

• AMD Radeon™ RX 9070 XT GPU
• AMD RDNA™ 4 Architecture
• 16GB GDDR6 Memory
• 256-bit Memory Interface
• 4096 Stream Processors
• 64 Compute Units
• 64 Ray Accelerators
• 128 AI Accelerators
• 64MB Infinity Cache
• Boost Clock up to 3060 MHz
• Game Clock up to 2520 MHz
• AMD HYPR-RX with AFMF 2
• AMD FidelityFX™ Super Resolution 4
• AMD Radiance Display™ Engine
• AMD Fluid Motion Frames 2
• DisplayPort™ 2.1a
• TRI-X Cooling Technology
• AeroCurve Fan Blade
• Honeywell PTM7950 Thermal Interface Material
• Metal Backplate
• ARGB Light Bar
• Fan Quick Connect
• Two-Ball-Bearing Fans
• 16-Phase Digital Power Design
• Intelligent Fan Control
• Precision Fan Control
• TriXX Support

Complete Technical Specifications

• Brand: SAPPHIRE
• Series: NITRO+
• Model: NITRO+ AMD Radeon™ RX 9070 XT OC GPU
• SKU: 11348-01-20G
• GPU: AMD Radeon™ RX 9070 XT
• Architecture: AMD RDNA™ 4
• Stream Processors: 4096
• Compute Units: 64 CUs
• Ray Accelerators: 64
• AI Accelerators: 128
• Infinity Cache: 64MB
• Boost Clock: Up to 3060 MHz
• Game Clock: Up to 2520 MHz
• Memory Size: 16GB
• Memory Type: GDDR6
• Memory Bus: 256-bit
• Memory Speed: 20 Gbps Effective
• Interface: PCI Express 5.0 x16
• BIOS Support: UEFI
• Game Index: 4K
• Maximum Displays: 4
• HDMI Resolution: Up to 7680 × 4320
• DisplayPort Resolution: Up to 7680 × 4320
• HDMI Outputs: 2
• DisplayPort Outputs: 2 × DisplayPort 2.1a
• Cooling: TRI-X
• Form Factor: 3.2 Slot, ATX
• Dimensions: 330.8 × 128.5 × 65.68 mm
• Typical Board Power: 330W
• Power Connector: 12V-2x6 (H++)
• Recommended PSU: Minimum 850W
• Operating System: Linux, Windows 10, Windows 11 64-bit

GPU

AMD Radeon™ RX 9070 XT

Video Memory

16GB GDDR6

Memory Interface

256-bit

Memory Speed

20 Gbps Effective

Boost Clock

Up to 3060 MHz

Game Clock

Up to 2520 MHz

Stream Processors

4096

Compute Units

64 CUs

Ray Accelerators

64

AI Accelerators

128

Infinity Cache

64MB

Interface

PCI Express 5.0 x16

Display Outputs

• 2 × HDMI
• 2 × DisplayPort 2.1a

Supports up to 4 displays with resolutions up to 7680 × 4320.

Cooling

SAPPHIRE TRI-X Cooling Technology

• AeroCurve Fan Blade
• Free Flow
• Integrated Cooling Module
• High TG Copper PCB
• Optimized Composite Heatpipes
• Honeywell PTM7950 TIM
• Metal Backplate
• Two-Ball-Bearing Fans
• Fan Quick Connect
• Intelligent Fan Control
• Precision Fan Control

Power Requirements

• Typical Board Power: 330W
• Recommended PSU: Minimum 850W
• Power Connector: 12V-2x6 (H++)
• Included Adapter: 12V-2x6 to 3 × 8-pin PCI Express
• Interface: PCI Express 5.0 x16

Dimensions

330.8 × 128.5 × 65.68 mm

Compatibility

• PCI Express-based desktop PC
• One available PCI Express x16 graphics slot
• Minimum 8GB system memory
• 16GB system memory recommended
• Minimum 850W power supply
• Windows 10 64-bit
• Windows 11 64-bit
• Linux 64-bit

Package Includes

• L-Shape Support Bracket
• 3-pin 5V ARGB Cable
• Magnetic Backplate
• 12V-2x6(H++) to PCI Express 3×8-pin Power Adapter
