DeepCool PX1200G 1200W 80 PLUS Gold, ATX 3.0 Power Supply
DeepCool PX1200G 1200W 80 PLUS Gold, ATX 3.0 Power Supply
Couldn't load pickup availability
PAST, PRESENT, AND BEYOND
With the remarkable capability to offer thrice the total GPU power and double the system power for 0.1 ms, any concerns about power spikes are rendered obsolete. The PX1200G guarantees unwavering and steady power, catering to both legacy and next-gen PCs for the foreseeable future.
UNSURPASSED QUALITY
Dependable power is assured through the utilization of genuine Japanese 105C capacitors. Given the top-notch build quality of the PSU, the PX1200G is fully operational at altitudes up to 5000 meters above sea level.
ROCK-SOLID STABILITY
Leveraging a dual main capacitor configuration, the PX1200G effortlessly maintains a hold-up time of ≥ 16ms even under full load conditions.
MASTERY OF PCI-E 5.0 POWER
Enhanced with the novel PCI-e Gen 5.0 12VHPWR cable, the PX-G offers a staggering 600W to satiate the appetite of power-hungry GPUs.
FROM STATIC TO DYNAMIC
The PX1200G introduces the option to transition into semi-fanless operation. In its hybrid mode, the 135mm FDB fan intelligently adjusts beyond its zero RPM state when the system load reaches a specific threshold.
TRANQUILITY OF MIND
The PX1000G boasts a comprehensive range of safeguards, including OPP, OVP, SCP, OTP, OCP, and UVP, ensuring a serene and secure operation.
EMBRACING THE ELEGANCE OF GOLD
Bestowed with the esteemed 80 Plus Gold certification, affirming 90% efficiency under typical load conditions.
Specification,
| Type | ATX12V V3.0 |
| Product Dimensions | 150×160×86mm (W x L x H) |
| Efficiency certification | 80Plus GOLD/Cybenetics_Platinum |
| Fan Size | 135mm |
| Fan Bearing | FDB (Fluid Dynamic Bearing) |
| Topology | Active PFC + Half Bridge SRC LLC + DC to DC |
| Capacitors | Full Japan Electrolytic Capacitors |
| Power Good Signal | 100-150ms |
| Hold Up Time | ≥16ms |
| Efficiency | ≥90% Under Typical Load(50% Loading) |
| Protection | OPP/OVP/SCP/OTP/OCP/UVP |
| Operation Temperature | 0 - 40℃ |
| Regulatory | CE/FCC/CCC/TUV-RH/RCM/EAC/CAN ICES-003(B)/NMB-003(B)/UKCA/BIS/KC; |
| Erp Regulation | ErP 2014 |
| Environment Protection | WEEE/中国 RoHS/Triman |
| MTBF | 100,000 Hours |
