SAPPHIRE PURE AMD Radeon™ RX 9070 XT OC GPU 16GB GDDR6
SAPPHIRE PURE AMD Radeon™ RX 9070 XT OC GPU 16GB GDDR6
Couldn't load pickup availability
The SAPPHIRE PURE AMD Radeon™ RX 9070 XT OC GPU is a high-performance graphics card based on AMD RDNA™ 4 architecture, featuring 16GB of GDDR6 memory on a 256-bit bus. It offers a Boost Clock of up to 3010 MHz and a Game Clock of up to 2460 MHz, with 4096 Stream Processors, 64 Compute Units, 64 Ray Accelerators and 128 AI Accelerators.
The card features SAPPHIRE Tri-X Cooling Technology with AeroCurve Fan Blades, Free Flow airflow optimization, an Integrated Cooling Module, optimized composite heatpipes and dual-ball-bearing fans. It also includes Honeywell PTM7950 TIM, a metal backplate, FrameDefense construction and an ARGB SAPPHIRE logo.
It uses PCI-Express 5.0 x16 connectivity, provides two HDMI and two DisplayPort 2.1a outputs, supports up to four displays, and supports resolutions up to 7680 × 4320. The card has a 317W Typical Board Power rating and requires a minimum 750W power supply with two 8-pin power connectors.
Key Features
- AMD RDNA™ 4 Architecture
- AMD Radeon™ RX 9070 XT GPU
- Up to 3010 MHz Boost Clock
- Up to 2460 MHz Game Clock
- 16GB GDDR6 memory
- 256-bit memory bus
- 4096 Stream Processors
- 64 Compute Units
- 64 Ray Accelerators
- 128 AI Accelerators
- 64MB Infinity Cache
- SAPPHIRE Tri-X Cooling Technology
- Honeywell PTM7950 Thermal Interface Material
- AeroCurve Fan Blade
- Free Flow cooling design
- PCI-Express 5.0 x16
- 2 × HDMI and 2 × DisplayPort 2.1a
- AMD HYPR-RX with AFMF 2
- AMD FidelityFX™ Super Resolution 4 with AI Upscaling
- AMD Radiance Display™ Engine
- AMD Fluid Motion Frames 2
- ARGB SAPPHIRE Logo
- L-Shape Support Bracket included
Complete Technical Specifications
- Brand: SAPPHIRE
- Model: PURE AMD Radeon™ RX 9070 XT OC GPU
- Series: PURE RX 9000 Series
- GPU/CPU/Product Type: AMD Radeon™ RX 9070 XT Graphics Card
- Architecture: AMD RDNA™ 4
- Memory: 16GB
- Memory Type: GDDR6
- Memory Bus: 256-bit
- Memory Speed: 20 Gbps Effective
- Clock Speed: Boost Clock up to 3010 MHz; Game Clock up to 2460 MHz
- Interface: PCI-Express 5.0 x16
- Dimensions: 320 × 120.25 × 61.6 mm
- Power Consumption: 317W Typical Board Power
- Power Connector: 2 × 8-pin
- Recommended PSU: Minimum 750W
- Cooling: Tri-X Cooling, AeroCurve Fan Blade, Free Flow, Integrated Cooling Module, optimized composite heatpipes and two-ball-bearing fans
- Stream Processors: 4096
- Compute Units: 64 CUs
- Ray Accelerators: 64
- AI Accelerators: 128
- Infinity Cache: 64MB
- Maximum Displays: 4
- Maximum Resolution: 7680 × 4320
- HDMI: 2 × HDMI
- DisplayPort: 2 × DisplayPort 2.1a
- BIOS Support: UEFI
- Form Factor: 3-slot, ATX
- PCB: High TG Copper PCB, 12-layer 2oz copper
- Power Design: 14-Phase Digital Power Design
- Operating System: Linux®, Windows® 10 and Windows 11; 64-bit operating system required
- System Memory Requirement: Minimum 8GB; 16GB recommended
- Game Index: 4K
- SKU/P/N: 11348-02-20G
GPU Architecture
The SAPPHIRE PURE RX 9070 XT uses AMD RDNA™ 4 architecture with 64 Compute Units, third-generation Ray Accelerators and second-generation AI Accelerators.
Memory
The graphics card features 16GB of GDDR6 memory on a 256-bit memory bus with an effective memory speed of 20 Gbps.
Gaming Features
Supported features include AMD HYPR-RX with AFMF 2, AMD FidelityFX™ Super Resolution 4 with AI Upscaling, AMD Radiance Display™ Engine, AMD Fluid Motion Frames 2, AMD Radeon™ Anti-Lag 2, AMD FidelityFX™ technologies, AMD FreeSync™ technology, AMD Noise Suppression and AMD Software: Adrenalin Edition™.
Cooling System
The card uses SAPPHIRE Tri-X Cooling Technology, AeroCurve Fan Blades, Free Flow airflow optimization, an Integrated Cooling Module and optimized composite heatpipes. Dual-ball-bearing fans are used for cooling, while Honeywell PTM7950 TIM provides the thermal interface material.
Connectivity
The graphics card provides 2 × HDMI and 2 × DisplayPort 2.1a outputs. It uses a PCI-Express 5.0 x16 interface and supports up to four displays at resolutions up to 7680 × 4320.
Power Requirements
The SAPPHIRE PURE RX 9070 XT has a 317W Typical Board Power rating. SAPPHIRE specifies a minimum 750W power supply and two 8-pin power connectors.
Additional SAPPHIRE Features
The card includes FrameDefense, a metal backplate, High TG Copper PCB, 14-Phase Digital Power Design, Fuse Protection, Intelligent Fan Control, Precision Fan Control, SAPPHIRE TriXX support, Glow!, TriXX Boost and external RGB LED motherboard synchronization.
Compatibility
- PCI Express-based PC required
- One available PCI-Express x16 graphics slot required
- Minimum 750W power supply
- 2 × 8-pin power connectors required
- Minimum 8GB system memory
- 16GB system memory recommended
- Supports 64-bit Windows 10
- Supports Windows 11
- Supports Linux®
Package Includes
- SAPPHIRE PURE AMD Radeon™ RX 9070 XT OC GPU
- L-Shape Support Bracket
- 3-pin 5V ARGB Cable
